Wuxi Xuanyi Stainless Steel Co., Ltd. is one of the leading manufacturers and suppliers of light gauge stainless steel pipes for ordinary piping in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to wholesale bulk light gauge stainless steel pipes for ordinary piping made in China here from our factory.
Light gauge stainless steel pipes for ordinary piping by Wuxi Xuanyi Stainless Steel are made of premium stainless steel materials. Featuring light weight and easy installation, they can meet regular demands for fluid transportation and pipeline connection. While guaranteeing structural strength, they cut material consumption, making them widely used pipe materials for building water supply & drainage, gas transmission and HVAC systems.
Parameters
Steel Grade: 201, 304, 304L, 316, 316L, 409L, 430, etc.
Specification: JIS G3448
|
Outside Diameter (Su) |
Outside Diameter (mm) |
Wall Thickness (mm) |
Outside Diameter Tolerance (mm) |
Wall Thickness Tolerance (mm) |
Length Tolerance |
|
10 |
12.70 |
0.80 |
-0.37+0.00 |
± 0.12 |
≥ defined length |
|
13 |
15.88 |
0.80 |
-0.37+0.00 |
± 0.12 |
|
|
20 |
22.22 |
1.00 |
-0.37+0.00 |
± 0.12 |
|
|
25 |
28.58 |
1.00 |
-0.37+0.00 |
± 0.12 |
|
|
30 |
34.00 |
1.20 |
-0.34+0.34 |
± 0.12 |
|
|
40 |
42.70 |
1.20 |
-0.43+0.43 |
± 0.12 |
|
|
50 |
48.60 |
1.20 |
-0.49+0.49 |
± 0.12 |
|
|
60 |
60.50 |
1.50 |
-0.60+0.60 |
± 0.15 |
|
|
75 |
76.30 |
1.50 |
± 1% |
± 0.15 |
|
|
80 |
89.10 |
2.00 |
± 1% |
± 0.30 |
|
|
100 |
114.30 |
2.00 |
± 1% |
± 0.30 |
|
|
125 |
139.80 |
2.00 |
± 1% |
± 0.30 |
|
|
150 |
165.20 |
3.00 |
± 1% |
± 0.40 |
|
|
200 |
216.30 |
3.00 |
± 1% |
± 0.40 |
|
|
250 |
267.40 |
3.00 |
± 1% |
± 0.40 |
|
|
300 |
318.50 |
3.00 |
± 1% |
± 0.40 |
- MOQ:5 Tons
- Deliver Time:About 15-20 Workdays
- Payment Tems:T/T or L/C at sight
Application Of Pipe/ Tube
Widely adopted in cold and hot water conveying systems of residential buildings, commercial constructions and public facilities. Anti-rust with long service life, the tubes effectively secure safe water supply and lower later maintenance costs.
Suitable for indoor gas pipelines and supporting systems. Featuring reliable connections and excellent tightness, they meet requirements for long-term stable operation and enhance the safety of pipeline systems.
Applicable to urban water supply networks, secondary water supply and public infrastructure. With outstanding durability and stability, they deliver reliable guarantee for long-term water supply.
Why Choose Us
Wuxi Xuanyi Stainless Steel Co., Ltd. was founded in 2011. Located in Wuxi, China, we are a professional stainless steel supplier and processing service provider. Supported by stable resources from major steel mills, a stringent quality management system and extensive export experience, we offer a full range of stainless steel products and customized solutions to clients worldwide. We always prioritize quality, efficiency and customer satisfaction. With reliable products, competitive pricing and on-time delivery, we strive to create long-term value for global partners.
Different Orders Need Different Arrangements
Purchasing needs vary from customer to customer. Some require regular supply of fixed specifications, while others purchase for individual projects, small batches or orders containing multiple sizes. Xuanyi arranges supply according to the actual order rather than applying the same ordering conditions to every inquiry. Mixed specifications, mixed packing, cut-to-length requirements, special packing and other non-standard requests can be discussed in advance based on material availability and processing conditions.
FAQ
Q: When is light gauge stainless steel pipe a suitable choice?
A: For general conveying, equipment connections and piping systems that do not require heavy-wall pressure-service pipe, light gauge tubes offer lower weight and can make handling, piping layout and installation more convenient.
Q: Is a thinner wall always better for light gauge stainless steel pipes?
A: No. Wall thickness should still be selected according to pipe diameter, connection method, service conditions and project requirements. A thinner wall should not be selected simply to reduce material consumption.
Q: Can light gauge stainless steel pipes be supplied in cut lengths?
A: Yes. Cut lengths and end requirements can be confirmed according to the piping layout, reducing the need for additional cutting and adjustment at the installation site.
